Capsule Filling Machine CFM800/1200
The video of this machine
This series of Capsule filling Machines adopts a programmable control system, touch screen panel, speed-shift, and electronic automatic counter.
Fully automatic, it can complete the actions of position, separation, filling, and locking of capsules. All models are machined by advanced high-precision CNC tooling machines that guarantee reliable interchangeability of different capsule models.
It is suitable for conventional pharmaceutical products such as powder, pellets, granules, as well as for nutriceutical products such as herbs, vitamins, or even special products with sticky, abrasive, fibrous, or other properties. This space-saving machine provides a straightforward operation, format changeover, and dosage accuracy.
It is suitable for conventional pharmaceutical products such as powder, pellets, granules, as well as for nutriceutical products such as herbs, vitamins, or even special products with sticky, abrasive, fibrous, or other properties. This space-saving machine provides a straightforward operation, format changeover, and dosage accuracy.
Main Technical Parameters
Model: CFM800 CFM1200
No. of die orifice: 4 6 9
Max output (capsules/hour): 30000 48000 72000
Vacuum: 27 m³/h -0.02～0.08Mpa
Capsule number: No. 00-5
Filling percentage: ≥99.9﹪
Filling difference: ＜±3
Idle load noise dB(A): ＜70
Machine power: 380V 50HZ 3KW
Machine dimension: 800x750x1950mm
Machine weight: 850KG
